803700541 Electronic Solid of Revolution Replacement for XCMG XCA100 All-Terrain Crane

Toprun Parts is a professional supplier of XCMG construction machinery safety electronic spare parts for more than 15 years. The 803700541 Electronic Solid of Revolution is a core rotary electronic sensing component exclusively matched for XCMG XCA100 all-terrain crane. It is installed on the crane slewing turntable to real-time collect rotation angle, rotary speed and position signals, and transmit accurate data to the load moment limiter system. Our replacement electronic revolution component strictly follows OEM production standards, effectively solving common failures including signal loss, unstable data, delayed alarm and sensor breakdown of original XCA100 rotary electronic parts.

1. Product Overview of 803700541 XCMG XCA100 Electronic Solid of Revolution

Part No.: 803700541
Standard Name: High Precision Electronic Solid of Revolution Rotary Sensor Assembly
Installation Position: XCMG XCA100 crane slewing support turntable
Matching Control System: XCMG original load moment limiter (LMI) safety control system
Working Voltage: DC 24V (crane standard power supply)
Core Function: Detect 360° slewing rotation angle, output stable digital signal to crane main controller, realize overload protection, anti-tipping safety monitoring and accurate lifting positioning.

This electronic solid of revolution integrates precision sensing chip, wear-resistant rotary conductive ring, sealed housing and signal wiring harness as one complete assembly. All internal electronic core components adopt industrial grade anti-interference chips, with excellent dustproof, waterproof and shockproof performance. It fully matches the installation hole size, wiring interface and program parameters of XCMG XCA100 all-terrain crane, plug-and-play without program modification during on-site replacement maintenance.

2. Core Advantages of XCMG 803700541 Electronic Rotary Sensor

• High precision signal collection: Real-time capture 0.01° rotation angle data, ensure precise safety calculation of LMI system

• Strong anti-electromagnetic interference: Industrial shielding structure, stable signal output under complex construction site electrical environment

• IP65 waterproof & dustproof housing: Adapt to rainy, dusty, muddy outdoor construction working conditions

• Anti-vibration and impact resistant: Internal components fixed with shock-absorbing structure, suitable for high-frequency slewing operation of all-terrain cranes

• Long service life conductive ring: Low friction rotary conductive structure, reduce signal attenuation after long-term continuous rotation

• 100% OEM interchangeable: Consistent outline size, wiring pin definition and communication protocol with original XCMG spare parts

• Safety guarantee: Effectively avoid crane overload, tipping and misoperation risks caused by sensor signal failure

3. Complete Technical Specification Table

4. Compatible XCMG All-Terrain Crane Models

The 803700541 Electronic Solid of Revolution is specially customized for XCMG XCA100 all-terrain crane. It also supports matching partial XCA series models with the same slewing electronic control system: XCA90, XCA100, XCA110 all-terrain cranes.

If you cannot confirm your crane chassis serial number or control system version, send detailed equipment information to our technical engineers for accurate part matching verification.

5. Matching Supporting Safety & Hydraulic Spare Parts (Internal Links)

We supply full set matched spare parts supporting 803700541 XCA100 rotary electronic sensor, click internal links to view product details:

• Load Moment Limiter System Assembly for XCMG Crane

• 803092077 Slewing Hydraulic Motor for XCMG Crane

• 803081151 Double Variable Piston Pump XCMG Crane Main Pump

• Boom Angle & Length Electronic Sensor XCMG

• Slewing Bearing Seal Repair Kit for XCMG XCA Series

All matched electronic, hydraulic and sealing spare parts are in warehouse stock, realize one-stop procurement of XCMG all-terrain crane complete system parts to save your procurement and international logistics costs.

6. Toprun Parts Supply & Service Advantages

Toprun Parts focuses on global export of XCMG, Zoomlion, Weichai construction machinery replacement spare parts, products exported to Central Asia, Middle East, Southeast Asia, Africa, Latin America and Eastern Europe markets.

• Large warehouse stock of XCMG crane electronic sensors, hydraulic pumps, slewing motors, seal kits and engine spare parts

• Support small trial order, MOQ 1 piece for local repair shops, crane rental companies and machinery dealers

• Professional electronic engineer team provides model matching, wiring guidance and crane control system fault troubleshooting

• Long-term bulk wholesale discount for global construction machinery distributors

• Strict factory inspection: Each electronic solid of revolution passes signal stability and waterproof aging test before delivery

• Accept customized neutral packaging without Toprun logo for resale dealers

7. Export Packing & Global Delivery Information

• Internal Packing: Shockproof EPE foam independent packaging to protect precision electronic chip from collision damage

• Outer Packing: Export fumigated solid wooden case for sea freight long-distance transportation

• Delivery Time: Goods arranged shipment within 2–5 working days after deposit confirmation

• Logistics Choices: Sea freight, air freight, DHL/Fedex/TNT international express available

• Custom Clearance Documents: Provide commercial invoice, packing list, packing declaration for smooth customs clearance in destination countries
