Cable Drum 803744959
Cable Drum 803744959
Cable Drum 803744959
Cable Drum 803744959
Cable Drum 803744959
Cable Drum 803744959

Cable Drum 803744959

Product Name：XCA100 Cable Drum Assembly Part Number：803744959 Applicable Machine：XCMG XCA100 All Terrain Crane（100ton） Product Type：Crane Electrical System / Cable Management Reel Quality：Genuine Original / OEM Replacement Warranty：12 Months Stock Status：In Stock, Shipment within 7-15 working days Packing：Export Standard Plywood Case Supplier：Qingdao Top Run International Trade Co.,Ltd Website：https://www.toprunparts.com/

Product Introduction

803744959 XCA100 Cable Drum | XCMG All Terrain Crane Cable Reel

Product Overview of 803744959 XCA100 Cable Drum

The 803744959 XCA100 Cable Drum is an essential electrical system component designed exclusively for the XCMG XCA100 100-ton all terrain crane. It serves as the core cable management device, responsible for orderly winding, storing, and releasing power cables and control signal cables during crane telescoping, luffing, and slewing operations.

This XCMG cable reel ensures stable power supply and reliable signal transmission between the crane’s upper structure and chassis, effectively preventing cable tangling, excessive bending, and tensile damage. Toprunparts keeps large stock of the genuine 803744959 cable drum, supporting global wholesale and retail for crane maintenance and repair. Every unit is 100% factory tested for insulation, conductivity, and rotation smoothness before delivery.

Technical Specifications

SpecificationData
Part Number803744959
Product NameXCA100 Cable Drum Assembly
ApplicationXCMG XCA100 All Terrain Crane
Drum MaterialHigh-strength steel + anti-rust coating
Rated Voltage380V / 50Hz
Slip Ring Rating63A / 10A (Power + Signal)
Cable Capacity25–35mm² power + control cables
Gross Weight45 KG
Quality LevelOriginal OEM / Genuine

Key Features & Advantages

  • Perfect Fit for XCA100: 1:1 original dimensions, direct bolt-on replacement.

  • Heavy-Duty Construction: Reinforced steel drum, corrosion-resistant coating.

  • Reliable Slip Ring System: Stable power and signal transmission, low contact resistance.

  • Precision Tension Control: Smooth rotation, consistent cable tension, anti-damage.

  • Strict Quality Control: Insulation, voltage withstand and dynamic rotation tested.

  • Cost-Effective & Fast Delivery: Factory price, large stock, 12-month warranty.

Compatible XCMG Equipment

  • XCMG All Terrain Crane: XCA100 (100 ton) full series

Packing & Delivery

All 803744959 XCA100 cable drums are packed in export-grade plywood cases with foam inner protection to avoid collision, deformation, and moisture during long-distance shipping. We support sea freight, air freight, and door-to-door delivery worldwide.

Related XCMG Spare Parts

XCMG All Terrain Crane Full Spare Parts

XCMG Crane Electrical System Parts

XCA100 Complete Replacement Parts

Why Choose Toprunparts

Toprunparts specializes in XCMG, SANY, Zoomlion construction machinery spare parts for over 15 years. We have a 10,000㎡ warehouse with abundant genuine and OEM parts in stock, providing professional technical support, competitive pricing, and reliable after-sales service for global customers.
