Product Name: Boom Length Measuring Sensor

Part Number: 803591493

Matching Model: D8.4DJ.1500.M134.3612

Applicable Equipment: XCMG XCA100 100 Ton All Terrain Crane

Core Function: Detect boom extension length and inclination angle

Protection Class: IP67 Waterproof & Dustproof

Output Signal: CAN Bus Signal

Quality: 100% New / OEM Replacement

Warranty: 12 Months

Stock: In Stock & Ready to Ship

Delivery Time: 4-7 Working Days

Package: Export Shockproof Carton

803591493 Length Sensor for XCMG XCA100 All Terrain Crane

Product Overview

The 803591493 length sensor (Model D8.4DJ.1500.M134.3612) is an essential electronic spare part exclusively designed for XCMG XCA100 100-ton all terrain crane. As a key component of the crane load moment limiter system, this boom length sensor is installed inside the six-section main boom of XCA100 crane, which has a maximum extension length of 60 meters. It collects real-time data of boom extension length and working angle, and transmits stable CAN bus signals to the crane main controller and cab display. This part effectively prevents overload and over-range operation, ensuring safe lifting in construction, mining and road engineering. All 803591493 sensors are fully tested for precision, signal stability and sealing before delivery. Toprunparts keeps abundant stock of XCMG crane electronic parts to serve global maintenance shops, leasing companies and engineering contractors.

Main Features & Product Strengths

• Dual detection design: One sensor realizes real-time monitoring of boom length and angle, compact and highly integrated structure.

• High measurement accuracy: Length nonlinearity ≤0.2%, angle precision up to 0.1%, stable output for long-term operation.

• IP67 full sealing: Resist rain, dust, mud splash, perfectly adapt to various harsh outdoor working environments.

• Original matching signal: Standard CAN bus output, plug and play, no program modification or extra debugging required.

• Durable internal structure: Adopts high-strength retractable steel wire rope, anti-jam and anti-aging, long service life under frequent telescopic work.

• 1:1 OEM size: Direct replacement for damaged original sensors, simple installation without any cutting or drilling.

• Reliable after-sales service: 12-month global warranty and professional remote technical support for installation and troubleshooting.

Detailed Technical Parameters

Compatible XCMG Crane Models

The 803591493 length sensor is specially customized for XCMG XCA100 series all terrain cranes, and it is compatible with the following models:

• XCMG XCA100 Standard 100 Ton All Terrain Crane

• XCMG XCA100 Upgraded Version All Terrain Crane

If you are not sure about the compatibility, please send your crane VIN code or original part number to us. Our technical team will complete the verification within 24 hours.

Installation & Working Principle

This pull-wire type length sensor is fixed at the bottom of the crane main boom, and the built-in steel wire rope is connected to the top boom head. When the boom stretches or retracts, the mechanical displacement is converted into standard digital signals by internal precision components. The signals will be displayed on the cab instrument and linked to the load protection system to realize automatic alarm and safety interlock. During installation, please keep the steel wire rope straight to avoid extrusion and distortion, which can effectively extend the service life of the sensor.

Related XCMG Spare Parts

Discover more matching spare parts for XCMG construction machinery:

Full Range XCMG Crane Spare Parts

Crane Electronic Sensors & Components

XCMG Hydraulic Pumps & Hydraulic Parts

Contact Us for Quotation & Technical Support

Why Choose Toprunparts

Qingdao Top Run International Trade Co., Ltd has more than 15 years of experience in exporting construction machinery spare parts. We supply genuine and OEM parts for XCMG, SANY, Zoomlion, Shantui, Liugong and other well-known brands. Our warehouse covers over 10,000 square meters with sufficient inventory, strict quality inspection and competitive factory prices. Our products are exported to more than 100 countries including Africa, Latin America, the Middle East, Russia and Southeast Asia. We support sea freight, air freight and international express, and provide one-stop purchasing and complete after-sales services. Choose our 803591493 length sensor to restore your XCA100 crane to normal working condition and reduce downtime!
